ZEISS PENTERO 800 S

Technical Specifications

  • ZEISS PENTERO 800 S

Specifications

ZEISS PENTERO 800 S

Technical Data

Rated Voltage

100 V - 240 V AC

Current Consumption

Max. 1.200 VA

Rated Frequency

50 Hz-60 Hz

Electrical Standard

IEC 60601-1, IEC 60601-1-2, IEC 60825, IEC 62304, CAN/CSA-C22.2 NO. 60601-1

Degree of protection against electric shock: Class 1

Class 2 laser product as per IEC 60825

Weight

Total weight of device with max. add. load: Max. 365 kg

Total weight of the device incl. single-use transport box: Approx. 800 kg

Packages
Standard
Spine Comfort
P&R Comfort

System

PENTERO 800 S basic system



Main Tubes

Straight binocular tube

o


180° tiltable tube

o

o

Foldable Tube f170/f260

o

o

Eyepieces

10x widefield eyepieces

o

o


12,5x widefield eyepieces

o

o

o

Focus

Laser Autofocus



Working Distance

200 – 500 mm


200 – 625 mm


Illumination

Xenon – Fully integrated Xenon light source with automatic lamp exchange



Co-Observation

Face-to-face with StereoBridge


Left/right with stereo co-observer

Tube for co-observation

Straight binocular tube

o

o

o

180° tiltable tube

o

o

o

Foldable Tube f170/f260

o

o

o

Balance

AutoBalance



XY-Movement

Angular movement with joystick or foot pedal




Video System

4K Video Package – Fully integrated 3-chip 4K camera, 2160p

o

o

o

4k 3D Video Package – 2x fully integrated 4K 3Chip camera, 2160p

o

o

o

Video Options

Video Recording




HD Video-In




External 55” 4K 3D monitor with monitor cart

Fluorescence3 / QEVO

INFRARED 800 with FLOW 800 Option4



5

YELLOW 560

BLUE 400 (not for sale in the US)



QEVO (not for sale in the US)




Visualization

Integrated Depth+



MultiVision

Resolution Enhancer


Networking & Storage

Integrated 1TB hard drive

WLAN package




ZEISS Surgical Cloud and ZEISS Livestream Preparation

ZEISS Smart Services Package – Connectivity for ZEISS Smart Services

Shared Network Package – Storage on shared network directories

DICOM Package – Patient data exchange with PACS system via DICOM

LAN interface

Navigation

Navigation Package

Foot Control Panel

Foot Control Panel wired / wireless

● Basic
o Configurable
□ Option

  • 3

    YELLOW 560 and BLUE 400 can only be combined with INFRARED 800 compact, not with each other

  • 4

    For PENTERO 800 S the FLOW 800 option is not available

  • 5

    Preparation for one fluorescence module included; separate license necessary
