Humphrey Field Analyzer 3

Detect faster, identify better, preserve longer.

ZEISS Humphrey Field Analyzer 3

  • Guided Progression Analysis
  • SITA Faster
  • 24-2C

Guided Progression Analysis (GPA) is a function of HFA3

It allows the detection and assessment of changes in glaucoma progression using mixed SITA tests taken on any HFA instrument.

Informing your decision-making with GPA

Informing your decision-making with GPA

Is your patient recovering, stable, or getting worse? Check with GPA to find the answer. GPA helps you to prioritize or augment glaucoma treatment by assessing the probability of visual field impairment.

GPA adds value to your practice

Guided Progression Analysis (GPA) provides an overview of the patient’s entire visual field history, streamlines workflow and can improve clinical confidence. GPA simplifies and standardizes analysis of changes in glaucomatous visual fields. It highlights any changes from baseline that represent larger than expected clinical variability and provides plain-language messages whenever changes show consistent and statistically significant loss.

Visual Field Index™ (VFI™> ) Trend is a regression analysis of the VFI values. It plots visual field loss against the patients' age, as well as rate of progression.
Glaucoma Change Probability Map is designed to identify progression events in consecutive visits at individual test points.
GPA Alert displays a plan language message about the likelihood of disease progression.

If the (GPA) slope is steep, it gives a projection and tells me what I need to be doing. And it also helps me if we need to advance therapy and create a greater burden on the patient. I can show them their glaucoma. They see it. They understand it.

Robert Fechtner, MD

Professor and Chair, Dept. of Ophthalmology, SUNY Upstate Medical University, Syracuse, NY

Leveraging GPA for Glaucoma Management and Improved Outcomes

April Jasper, OD and Robert Fechtner, MD discuss Do’s, Don’ts and How-to's in a 12-minute conversation packed with tips, visuals and clinical examples proving that GPA is an easy to use and powerful “early warning“ system for glaucoma doctors and patients.

Illustration of an eye with the ten additional points for central visual field thanks to the the new SITA Faster 24-2C test.

Minimize time. Maximize information with 24-2C.

Reduce testing time by up to 50% with SITA Faster 24-2 threshold testing. The SITA Faster 24-2C test adds ten additional points for the central visual field. And the points selected cover the areas that are known to be susceptible to glaucomatous defects.

Threshold testing is faster than ever with SITA Faster 24-2

SITA Faster 24-2 improves clinical workflow and patient satisfaction with the fastest test time in HFA threshold testing. Approximately 50% faster than SITA Standard, SITA Faster 24-2 is also about 30% quicker than SITA Fast, yet offers the same reproducibility.

The animation shows typical test image ranges in minutes (mean +/- std. dev.)1

Tracking rate of progression more often in less time with SITA Faster

Prof. Anders Heijl, one of the inventors of SITA algorithms and a pioneer of computerized perimetry, explains why SITA Faster is on its way to becoming the new gold standard in visual field testing.

…the accuracy of the precision of SITA Faster should be the same as with SITA Fast… we consider the data between SITA Fast and SITA Faster to be completely interchangeable

Prof. Anders Heijl

Lund University, Sweden

Obtain more information in the central visual field

New SITA Faster 24-2C adds ten test points to the 24-2 pattern, which were selected to examine areas along physiologically relevant nerve fiber bundles known to be susceptible to glaucomatous defects.

SITA Faster with 24-2C: A winning combination

Dr. C. Gustavo De Moraes, an expert in structural and functional changes in glaucoma, explains how the SITA Faster 24-2C testing paradigm helps detecting early macular involvement in the central field defects and how this new test can help elevating glaucoma practice.

There is compelling evidence that even in early glaucoma cases, the macula may be affected, but you need to use an adequate test to make sure that damage is real.

Dr. C. Gustavo De Moraes

Columbia University, New York

The Evolution of Perimetry

As the engine driving ZEISS HFA, SITA has come a long way since it was first developed for Humphrey Field Analyzer. Today, the innovation first designed to optimize visual field testing is doing that and much more, for both doctors and patients. This video documentary narrated by the creators of the SITA algorithm, Prof. Anders Heijl and Prof. Boel Bengtsson, goes over the rich history and the current ambition of the ever evolving SITA.

A peer perspective

Listen to real world experiences from your peers on various aspects of how technologies have supported in improving patient education, compliance, management over time, and overall vision preservation.

Specifications HFA3

830

840

850

860

Test Specifications
Maximum temporal range (degrees)

90

Stimulus duration

200 ms

Visual field testing distance

30 cm

Background illumination

31.5 ASB

Threshold test library
24-2, 30-2, 10-2, Macula
60-4, Nasal step
Threshold test strategies
SITA Standard, SITA Fast, SITA Faster, Full Threshold, FastPac
SITA-SWAP
Suprathreshold test library
C40, C76, C80
C64, C-Armaly
Peripheral test patterns
Suprathreshold test modes
Age corrected
Threshold related, Single intensity
Specialty test library
Social Security Disability, monocular, binocular
Esterman monocular, binocular, superior 36, 64
Kinetic testing
Custom Kinetic testing
Custom Static testing

Downloads

    • HFA3 White Paper Liquid Lens 2016 EN

      File size: 106 KB
    • HFA TodayTomorrow - WhitePaper Dr. Epstein EN

      File size: 1 MB
    • HFA3 SITA Faster Whitepaper EN

      File size: 142 KB

Download your FREE copy of Excellent Perimetry 5th Edition

Select your version to receive the link via email.

Form is loading...

The information entered in the contact form will be used to answer your request by Carl Zeiss Meditec AG, our local Carl Zeiss Meditec sales companies via email or phone.

If you want to have more information on data processing at ZEISS please refer to our data privacy notice.

Get in touch with us!

Receive more information about the product and availability in your country!

Form is loading...

Personal contact information

If you want to have more information on data processing at ZEISS please refer to our data privacy notice

  • 1

    Heijl A1, Patella VM2, Chong LX3, Iwase A4, Leung CK5, Tuulonen A6, Lee GC2, Callan T2, Bengtsson B7. A new SITA perimetric threshold testing algorithm; construction and a multi-center clinical study. Am J Ophthalmol. 2018 Oct 15. pii: S0002-9394(18)30592-0. doi: 10.1016/j.ajo.2018.10.010. [Epub ahead of print]
